Beijing Infrared Times TH134 Portable Leeb Hardness Tester Instruction Manual

TH134 Leeb Hardness Tester is a new pocket type integrated hardness testing instrument, mainly suitable for testing the hardness of metal materials, with the characteristics of high testing accuracy, small size, easy operation, convenient carrying and wide measuring range. It is based on Leeb hardness is the principle, the measured Leeb (HL) hardness value is automatically converted into Brinell, Rockwell, Vickers, Shore and other hardness values ​​through the program, and various test accessories can also be configured to meet various test conditions It is mainly suitable for rapid hardness testing of metal materials, especially suitable for on-site hardness testing of large parts and non-detachable parts.

Features

● TH134 integrated Leeb Hardness Tester is a professional pocket-sized hardness testing instrument, which is easy to carry;

● TH134 is equipped with DL type impact device;

● Direct testing of large, heavy test pieces or permanent assembly components;

● TH132 is more suitable for hardness measurement of parts such as deep groove bottom or profile surface (such as tooth surface);

● Can test six kinds of hardness (HV, HRC, HRB, HB, HV, HS);

● An external printer can be connected to print the test results
