Gloss meter measurement standard Daquan

Many industries have adopted the 20/60/85º geometry specified in ISO2813/ASTM D523, but see the table below for more information on specific industries and their industry standards.

General gloss measurement

• ASTM D523 1999 (USA)

• Specular Gloss Test Method

• The primary ASTM Specular Gloss Standard. Very similar to ISO 2813

• ASTM D3928 1998 (USA)

• Test Method for Evaluation of Gloss or Gloss Uniformity

• ASTM D4039 1999 (USA)

• test method for reflective haze of glossy surfaces

• ASTM D4449 1999 (USA)

• Test method for visual evaluation of gloss differences between surfaces of similar appearance

• ASTM D5767 1999 (USA)

• Test method for instrumental measurement of image gloss of coating surfaces

• ASTM E430 1997 (USA)

• test Method for Measuring Gloss of High Gloss Surfaces by Goniophotometry

• MFT 30-064 (South Africa)

• Native version of ASTM D523

• JIS Z8741 1997 (Japan)

• How to measure specular gloss

painting

• IS0 2813 1994 (International)

• Paints and varnishes -- Determination of specular gloss at 20°, 60° and 85° of non-metallic paint films

• The primary ISO specular gloss standard. Very similar to ASTM D523

• The following is technically similar to ISO 2813:

• BS 3900:1995 Part D5 (UK)

• Test methods for paints - Optical testing of paint films - Measurement of specular gloss at 20°, 60° and 85° of non-metallic paint films

• DIN 67530 1982 (Germany)

• Reflectometer as a means of evaluating the specular gloss of smooth painted and plastic surfaces

• NFT 30-064 1999 (France)

• Paints -- Measurement of specular gloss

• at 20, 60 and 85°.

• AS 1580 MTD 602.2 1996 (Australia)

• Paints and related materials, test methods - introduction and list of methods

• JIS Z8741 1997 (Japan)

• Specular Gloss - Method of Measurement.

• SS 18 41 84 1982 (Sweden)

• Paints and Varnishes - Measurement of specular gloss at 20, 60 and 85° of non-metallic paint films

plastic

• BS 2782: Part 5, Method 520A 1992

• Test methods for plastics -- Optical and color properties, weatherability -- Determination of specular gloss

• Similar to ISO 2813

• ASTM D2457 1990

• Test method for specular gloss of plastic films and solid plastics

• The primary standard is specified as mirrors with defined gloss values of 1000, 20°, 60° and 45°; the 45° method is the same as ASTM C346 for ceramics.

Metal

• BS6161: Part 12 of 1987

• Test Method for Anodized Coatings on Aluminum and Its Alloys - Measurement of Specular Reflectance and Specular Gloss at 20°, 45°, 60° or 85° Angles

• refer to. Standard BS 3900: Part D5 (1980); technically equivalent to ISO 7668 replacing BS 1615:1972. At 45°, the source image and receiver apertures are the same size as at 60°. It is also recommended to use a square with side lengths equal to the shorter side of the rectangle. Alternatively, using total reflection in a 45° prism as a reference; source image and receiver apertures are circular with an angular diameter of 3.44° ± 0.23° each (1.5 mm ± 0.1 mm at 25.4 mm focal length)

• ISO 7668 1986

• Anodized Aluminum and Aluminum Alloys - Measure Specular Reflectance and Specular Gloss at 20°, 45°, 60° or 85° angles.

• IS0 5190

• Anodizing of aluminum and its alloys -- Evaluation of the uniformity of appearance of architectural anodized finishes -- Determination of diffuse reflectance and specular gloss

• ECCA T2 (European Coil Coating Association)

• 60° mirror gloss.

Paper

• DIN 54502 1992

• Testing of paper and board; reflectometer as a means of gloss assessment of paper and board

• ASTM D1223 1998

• Test method for paper and paperboard specular gloss at 75°.

• Has an unusual converging beam geometry. Specify the primary standard as black glass with a defined gloss value of 100 at the sodium D-line with a refractive index of 1.540 instead of 1.567.

• ASTM D1834 1995

• Test method for 20° specular gloss of stenciled paper

• Another unusual converging beam geometry, different from the previous one.

• TAPPI T480 OM-90 1990 (USA)

• Specular gloss at 75° for paper and board

• Same text as ASTM D 1223

• Tapie 653 1990

• Specular gloss of wax paper and cardboard at 20°

• Possibly the same text as ASTM D 1834

• JIS-Z8142 1993 (Japan)

• 75° Specular Gloss Test Method

furniture

• BS 3962:1980 Part 1

• Test Method for Wooden Furniture Finishes - Evaluation of Low Angle Glare by Measuring 85° Specular Gloss

• Similar to ISO 2813 : 1978

• floor polish

• ASTM D1455 1987

• Test method for 60° specular gloss of latex floor polish

• refer to. Standard ASTM D 523

ceramics

• ASTM C346 1987

• Test method for 45° specular gloss of ceramic materials

• refer to. Standard ASTM D 523

• ASTM C584 1981

• Test method for 60° specular gloss of glazed ceramic ware and related products

• refer to. Standard ASTM D 523 {Gloss}

the fabric

• BS 3424: Method 31: Part 28 of 1993

• Testing coated fabrics -- Determination of specular gloss
