CNSHP DC-6515 Digital Display Thermostatic Bath -65 ℃/15L

DC6515

Thermostatic Bath

Introduction

The microcomputer temperature-controlled low-temperature constant temperature tank adopts single-chip micro-processing control, self-tuning PID adjustment, imported high-precision platinum resistance (Pt100) temperature measurement, high temperature control accuracy, and small fluctuations; the compressor with good fully enclosed technology (less than - The 40°C or 30L series adopts fully imported double compressor cascade refrigeration technology and heat exchange system), with high refrigeration efficiency and low noise. The instrument works stably and reliably, and is easy and safe to operate.

Humanized design: Foldable handles on both sides are convenient for carrying the instrument, 20L and above series and low-temperature constant temperature bath below -40℃ adopt heavy-duty self-locking casters for easy movement. The low-temperature constant temperature bath adopts a professional overall foaming process, which has good heat insulation performance and effectively reduces the loss of cooling capacity.

Professional circulation stirring design: ensure that the liquid in the tank is dispersed evenly and smoothly in the internal circulation, and the heat exchange is stable. The volume of the Low Temperature Circulating Bath above 20L is 10L/min, the flow rate of the stirring pump is 10L/min, the rest is 8L/min, the temperature fluctuation is ±0.05℃, and the display resolution is 0.1℃.

Suitable for internal/external temperature control applications: the sample can be directly placed in an open bath to keep the temperature constant, and it can also be connected externally to control the external measurement unit that needs constant temperature.

Features

1. It adopts microcomputer temperature control PID adjustment and self-tuning control technology, and the temperature control accuracy reaches ± 0.05°C

2. Fully enclosed brand compressor refrigeration system, no CFC, fast cooling.

3. Temperature range: optional -50～100℃ (pure water, ethylene glycol, alcohol, etc. are selected as the medium according to the temperature range), and customized products can also be designed and produced in full accordance with user requirements

4. Capacity range: 6L, 10L, 15L, 20L, 30L. Customized products can also be designed and produced in full accordance with user requirements.

5. The shell of the fuselage adopts anti-aging electrostatic plastic spraying technology, and the stirring pump of the platform liner is all made of high-quality SUS304 stainless steel materials, with excellent workmanship;

6. The fine workmanship of the front panel and table top of the chassis, coupled with the unique humanized R rounded corner design structure, can prevent the operator from being injured by the corners inadvertently.

7. Detachable ventilation grill for easy cleaning of the condenser of the refrigeration unit

8. Internal circulation function: Adopt a heatless centrifugal circulation pump to avoid the influence of the traditional water pump on the temperature field of the tank due to its own heat generation.

9. External circulation function: the circulation pump can conduct external circulation of constant temperature liquid to establish a second temperature field.

10. Low temperature constant temperature bath safety protection device:

1) With power-off protection function

2) With upper and lower limit temperature setting function

3) Temperature runaway protection and alarm function

4) The heating device has low water level anti-dry and explosion-proof functions

5) Multiple protection functions for compressor overheating and overcurrent

6) There is a sensor open circuit display function;

Applications

DC series low-temperature constant temperature bath is widely used in bioengineering, medicine, food, chemical industry, metallurgy, chemical analysis, petroleum and other fields, providing users with a high-precision, controlled, and uniform temperature constant field source. Colleges, factories, laboratories, and quality inspection departments provide users with a liquid environment with controlled heat and cold and uniform temperature when they work, and directly conduct constant temperature tests or tests on test samples or produced products in the tank, which can be used for direct Heating or cooling, as a temperature source for auxiliary heating or cooling, such as temperature control for reactors, fully automatic synthesis instruments, extraction and condensation devices.

Application

Constant temperature field: sensor detection, constant temperature biochemical reaction, constant temperature material aging, etc.

Biochemical field: rotary evaporator, Abbe refractometer, viscometer, rheometer, polarimeter, atomic absorption, ICP-MS, ICP, nuclear magnetic resonance, CCD, biological fermentation tank, chemical reactor (synthesizer), etc.

Materials field: Electron microscope, X-ray diffraction, X-ray fluorescence, vacuum sputtering plating, vacuum coating machine, ICP etching, various semiconductor equipment, fatigue testing machine, chemical deposition system, atomic deposition system, etc.

Medical field: superconducting magnetic resonance, linear accelerator, CT, low magnetic field nuclear magnetic resonance, X-ray machine, microwave therapy machine, medical cold cap, cooling blanket, etc.

Physical and chemical fields: lasers, magnetic fields, various molecular pumps, diffusion pumps, ion pumps, and materials.

Packing list：machine X1, manual X1, certificate X1, warranty card X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
