INGERSOLL RAND v5-8 Air Compressor, Displacement 780L/min Motor Power 5.5KW
SE
v5-8
Ingersoll Rand v5-8 Air CompressorSPEC
Ingersoll Rand v5-8 Air CompressorDetails
Ingersoll Rand v5-8 Air CompressorPacking list
- SKU
- NB010397
- type
- fuel injection
- compression method
- screw type
- exhaust pressure
- 800kpa
- Displacement
- 780L/min
- output power
- 5.5KW
- noise value
- 65±3dB(A)
- Dimensions
- 826*759*782mm
- Weight
- 280Kg
- Cooling mode
- A/C
Innovative modular design, high integration leads to high reliability
| Host module — Durable Ingersoll Rand main engine: effective and stable, its performance has been verified and recognized by millions of Air Compressor customers equipped with modified main engine in Chinese market — Fully integrated host, discrete system, and internal connection piping — Built-in piping eliminates leakage at hoses and fittings — Effective separation system with rotatable detachable oil separator core |
|
Cooling module — Integrated cooler integrates oil cooling and aftercooling — Top exhaust air to avoid hot gas backflow and optimize cooling efficiency — Centrifugal integrated cooling fan, eliminating the need for a fan motor and saving energy — Low operating noise
|
| Control module — High temperature shutdown protection — Motor overload protection — Overpressure safety decompression system |
|
Transmission drive module — Imported Poly-V belt, longer life than traditional belt — Four shock absorbing pads are standard to reduce vibration and noise — Long-term lubrication of the front and rear bearings of the motor |
Silent design
| — Centrifugal cooling fan for optimal cooling and reduced noise and vibration — Adopt closed silent box design, sheet metal soundproof cover, 3-5dB (A) lower than general Air Compressor. |
Independent system of hot and cold chambers
| — Unique independent system design of cold and hot chambers, the internal layout of the unit is more reasonable — Placing electrical components and oil separation and filtration modules, which are susceptible to damage from high temperatures, in a cold chamber increases the service life of the unit |
User-friendly design, fast self-service
Air Compressor performance parameters
Models | pressure | Motor power | Exhaust volume | noises | Dimensions(mm) | weight | ||
barg | kW | m3/min | dB(A) | long | wide | high | Kg | |
V5-7 | 7 | 5.5 | 0.83 | 65±3 | 826 | 759 | 782 | 280 |
V5-8 | 8 | 5.5 | 0.78 | 65±3 | 826 | 759 | 782 | 280 |
V5-10 | 10 | 5.5 | 0.70 | 65±3 | 826 | 759 | 782 | 280 |
V7-7 | 7 | 7.5 | 1.10 | 65±3 | 826 | 759 | 782 | 280 |
V7-8 | 8 | 7.5 | 1.03 | 65±3 | 826 | 759 | 782 | 280 |
V7-10 | 10 | 7.5 | 0.91 | 65±3 | 826 | 759 | 782 | 280 |
V11-7 | 7 | 11 | 1.63 | 65±3 | 826 | 759 | 782 | 280 |
V11-8 | 8 | 11 | 1.52 | 65±3 | 826 | 759 | 782 | 280 |
V11-10 | 10 | 11 | 1.35 | 65±3 | 826 | 759 | 782 | 280 |
Tested in accordance with PNEUROP/CAGI test standards
Tested in accordance with ISO 2151:2004 annex C test standard
Inlet air temperature collection point: the outside of the unit housing
Exhaust volume collection point: the exhaust point outside the unit shell
Exhaust pressure collection point: the exhaust point outside the unit housing
