Specifications
| maximum temperature | 1300℃ |
| Temperature range | ≤1200℃ |
| Heating workpiece | silicon carbide rod |
| Furnace Volume | 3.7L |
| Heating power | 4KW |
| Temperature control Accuracy | ±1℃ |
| Heating rate | ≤15℃/min |
| Temperature control instrument | LCD/smart PID temperature control |
| Thermocouple | S-type Thermocouple |
| Furnace size | 250*150*100mm |
| Power supply Voltage | AC220V 50Hz |
| Dimensions | 650*550*700mm |
Packing list
Resistance furnace x1, manual x1, certificate x1, Encasement box x1
After-sales instructions
Warranty days: 365 days
1. The warranty period is 1 year;
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period (except for improper use), and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1052/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
