Specifications
| Display | 5-Inch color touchscreen |
| Measurement range | 1~2000000mPa·s |
| Rotor specification | 1#、 2#、3#、4# |
| Rotor speed | 0.3/0.6/1.5/3/6/12/30/60rpm |
| Reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1%F.S |
| Power supply Voltage | Wide Voltage operation (110V/60Hz or 220V/50Hz) |
| Dimensions | 300*300*450mm |
| Weight | 4kg |
| Capacity | 300~400ml |
| Showing shear strain/shear rate | Standard |
| Timer | Standard |
| Linear dispersion | Real-time display of viscosity Linear dispersion |
| Kinematic viscosity | Display after entering the density of the sample |
| Temperature sensor | Standard temperature sensor interface (optional temperature sensor is required) |
| Automatic scan function | Automatically scan and recommend the right combination of rotor and Rotation speed |
| Save measurement results | Up to 30 sets can be stored (including rotor, Rotation speed, temperature, time, etc.) |
| Save measurement results | Save up to 30 sets of data (including viscosity, temperature, rotor, Rotation speed, shear rate, shear stress, time, density, kinematic viscosity, etc.) |
| Interface | Data, Linear dispersion printable (standard with print interface, optional printer required) |
| Thermostatic parts | Options (including various Viscometer Thermostatic baths, thermostatic cups,) |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/10824/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
