Specifications
| Display | 5-Inch color touchscreen |
| Measurement range | 1~200000mPa·s |
| Rotor specification | 21#、 27#、28#、29# |
| Rotor speed | 0.5/1/2/5/10/20/50rpm |
| Reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1%F.S |
| Power supply Voltage | Wide Voltage operation (110V/60Hz or 220V/50Hz) |
| Dimensions | 300*300*450mm |
| Weight | 4kg |
| Capacity | 15~25ml |
| Showing shear strain/shear rate | without |
| Timer | Standard |
| Linear dispersion | Real-time display of viscosity Linear dispersion |
| Kinematic viscosity | Display after entering the density of the sample |
| Temperature sensor | Standard temperature sensor interface (optional temperature sensor is required) |
| Automatic scan function | Automatically scan and recommend the right combination of rotor and Rotation speed |
| Save measurement results | Up to 30 sets can be stored (including rotor, Rotation speed, temperature, time, etc.) |
| Save measurement results | Save up to 30 sets of data (including viscosity, temperature, rotor, Rotation speed, shear rate, shear stress, time, density, kinematic viscosity, etc.) |
| Interface | Data, Linear dispersion printable (standard with print interface, optional printer required) |
| Thermostatic parts | Options (including various Viscometer Thermostatic baths, thermostatic cups,) |
Packing list
Viscometer host x1, rotor x1 (21 #, 27 #, 28 #, 29 #sets), triangular base x1, column x1, sample container cup x1, power adapter x1, instrument aluminum box gold foil x1, sample cylinder x1 rotor protection frame x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/10827/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
