Specifications
| Display | 5-Inch color touchscreen |
| Measurement range | 10~200000mPa·s |
| Rotor speed | 0.5/1/2/5/10/20/50rpm |
| Reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1%F.S |
| Power supply Voltage | 220V / 50Hz |
| Application standard | GB/T2794-1995；HG/T3660-1999T；JTG E20-2011 |
| Dimensions | 300*300*450mm |
| Weight | 10kg |
| Capacity | 15~25ml |
| Temperature range | RT+~250℃ |
| Temperature Accuracy | 0.1℃ |
| Timer | Flexible setting according to sample conditions |
| Linear dispersion | Real-time display of viscosity Linear dispersion |
| Save measurement results | 30 sets can be stored (including rotor, Rotation speed, temperature, time, etc.) |
| Interface | Data, Linear dispersion printable (standard with print interface, optional printer required) |
Packing list
Viscometer host * 1, lifting column * 1, base * 1, rotor (21 #, 27 #, 28 #, 29 #) * 4, operation manual * 1, heating furnace * 1, thermostat * 1, power adapter * 1, power cord * 1, sample cylinder * 2
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/10829/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
