Specifications
| Model technical parameters | DDSJ-318T |
| Instrument level | Level 0.5 |
| Measurement parameter | Conductivity, resistivity, total solids dissolved (TDS), salinity, ash, temperature |
| Conductivity range | 0.000μS/cm～2000mS/cm |
| EC minimum resolution | 0.001 μS/cm, automatically switched according to the range |
| resistivity range | 5.00Ω.cm～100.0MΩ.cm |
| Resistivity minimum resolution | 0.01Ω · cm, automatically switch according to the range |
| TDS range | 0.000 mg/L～1000g/L |
| Salinity range | (0.00～8.00)% |
| Salinity minimum resolution | 0.01% |
| Salinity electronic unit reference error | ±0.1% |
| Ash White Sugar Ash Measuring method, Ash of White Suga | support |
| Ash Fructose Syrup Ash Measuring method, Ash Content of HFCS | support |
| Temperature range | (-10.0～135.0)℃/(14.0-275.0)℉ |
| Temperature minimum resolution | 0.1 ℃/0.1℉ |
| Temperature electronic unit error of indication | ±0.1 ℃ |
| Power Supply | Power adapter (input: AC100~240V, output: DC24V) |
| Size (mm), Weight (kg) | 220×195×68，0.95 |
Packing list
Host x1, DJS-1D type Conductivity detector electrode (platinum black) x1, T-818-B-6 type temperature electrode x1, REX-3 type multifunctional electrode holder x1, general power supply (9VDC, 800mA, inner positive and outer negative) x1, RS232 communication cable x1, USB interface cable x1, TP-16 type serial printer cable x1, data collection disc x1, AF30 touch pen x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. The warranty period is 1 year (the electrode is a consumable and is not covered by the warranty);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period (except for improper use), and long-term technical support outside the warranty period.
