Specifications
| Measurement range | Determined by the probe |
| margin of error | ±1μm/±1~5% |
| resolution | 0.1μm|1μm|0.01mm |
| Minimum measurement surface | Depending on the probe |
| Calibrated mode | One point calibrated, two point calibrated |
| Unit display | μm/mils |
| statistical function | Statistics, MAX Maximum, MIN Minimum, Average, Standard deviation, Relative Standard deviation |
| icon function | Yes. |
| Data storage | Storage function for up to 10,000 Measured values |
| Power Supply | 3*1.5V AA |
| Standards | ISO 2178, ISO 2360 |
| Weight | 265g |
| Dimension | 198*92*35mm |
Packing list
Host (without probe) X1, probe line X1, Fe-based and non-Fe-based Calibration plate X1, calibration shim X2, Encasement box X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/11660/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
