Specifications
| Instrument level | Level 0.001 |
| Measurement parameters | pX value, Ion concentration value, mV, temperature value |
| Measurement range | pX: (0.000~14.000) pX; mV: (-1800~1800) mV; Ion concentration: (0~19990), unit ug/L, mg/L, g/L, mol/L, mmol/L; temperature: (-5.0~105.0) ℃ |
| Resolution | pX: 0.001 pX; mV: 0.1mV; Temperature: 0.1 ℃ |
| Electronic unit intrinsic error | pX: +/- 0.005pX +/- 1 word; mv: +/- 0.03% FS; Ion concentration ： +/- 0.5% +/- 1 word; temperature: +/- 0.3 ℃ +/- 1 word |
| Power Supply | DC universal Power Supply (9VDC, 500mA, internal positive and external negative) |
| Weight | 1kg |
| Dimensions | 290*200*70mm |
Packing list
Ion meter x1, 232-01 reference electrode x1, pF-2-01 fluorine electrode x1, T-818-B-6 type temperature electrode x1, Stirrer x1, general power supply x1, stirringrod (large, medium and small) x1, multifunctional electrode holder x1, TP-16 serial printer connection x1, RS-232 communication connection x1, pH standard buffer pH4,7,9 each x5, fuse x1, general power cord x1, data collection software x1, dust cover x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. The warranty period is 1 year (the electrode is a consumable and is not covered by the warranty);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period (except for improper use), and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1172/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
