Specifications
| Instrument level | Level 0.001 |
| Measurement parameters | pX value, Ion concentration value, mV, temperature value |
| Measurement range | pX: (0.000~14.000) pX; mV: (-1999.99~ 1999.99) mV; Ion concentration: (0~19990), unit ug/L, mg/L, g/L, mol/L, mmol/L; temperature: (-5.0~105.0) ℃ |
| Resolution | pX: 0.01 pX, 0.001 pX; mV: 0.1mV, 0.01mV; Temperature: 0.1 ℃ |
| Electronic unit intrinsic error | pX: pX Ⅰ： +/- 0.002pX +/- 1 word; pX Ⅱ： +/- 0.005pX +/- 1 word; mv: +/- 0.03% FS; Ion concentration ： +/- 0.5% +/- 1 word; temperature: +/- 0.2 ℃ +/- 1 word |
| Temperature compensation method | Manual/Automatic |
| Power Supply | AC (220±22)V；(50±1)Hz |
| Weight | 2kg |
| Temperature compensation range | 0~60℃ |
| Dimensions | 250*195*100mm |
Packing list
Ion meter x1, PF-2-01 fluorine electrode x1, 232-01 reference electrode x1, T-820-D type temperature electrode x1, Stirrer x1, multifunctional electrode holder x1, TP-16 type serial printer connection x1, RS232 communication cable x1, USB communication cable x1, stirringrod (large, medium, small) x1, dust cover x1, pH standard buffer pH4,7,9 each x5, fuse x2, AF30 touch pen x1, data collection software x1, international general power cord x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. The warranty period is 1 year (the electrode is a consumable and is not covered by the warranty);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period (except for improper use), and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1173/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
