Specifications
| Temperature range | RT+5~60℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±0.1℃ |
| Oscillation mode | cyclotron |
| Oscillation Frequency | 30~400rpm |
| Speed Accuracy | ±1rpm |
| Oscillation Stroke | Φ26mm |
| Maximum configuration | 50ml*20 or 100ml*16 or 250ml*12 or 500ml*9 |
| Pallet size | 295*245mm |
| Number of pallets | 1pcs |
| Liner size | 340*285*200mm |
| Timer Range | 0~999h |
| Dimension | 440*410*390mm |
| Net Weight | 31kg |
| Input Power | 220W |
| Power supply Voltage | AC 220V 50Hz |
| Display mode | LCD one-screen display |
| Environmental temperature | 5~40℃ |
| Door opening method | Open the door |
| Standard configuration | 50ml*4100ml*4250ml*3 500ml * 3 sticks |
| Volume | 20L |
Packing list
integrated host x1, power cord x1, manual x1, certificate x1, warranty card x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/11972/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
