Brand：JieCheng
Model：TS-110X50
Name：Double-decked Extra Large Capacity Air Bath Shaker
Specifications
| Temperature range | RT+~99.9℃ |
| Temperature Resolution | 0.1℃ |
| refrigeration method | automatic |
| Compressor defrosting method | automatic |
| Temperature Fluctuation | ±0.1℃ |
| Oscillation mode | cyclotron |
| Oscillation Frequency | 0~200rpm |
| Speed Accuracy | ±1rpm |
| Oscillation Stroke | 35mm |
| Maximum configuration | 100ml*20 or250ml*15 or500ml*11 or 1000ml*6 |
| Pallet size | 970*560mm |
| Number of pallets | 2pcs |
| Liner size | 1120*640*830mm |
| Liner material | 304 #stainless steel |
| Timer Range | 0~999h |
| Lighting method | Built-in lighting, UV sterilization lamp |
| Dimension | 1200*800*1500mm |
| Net Weight | 380kg |
| Input Power | 960W |
| Power supply Voltage | AC 220V 50Hz |
| Display mode | LCD one-screen display |
| Environmental temperature | 5~40℃ |
| Standard configuration | 250ml*15 |
| Volume | 595L |
Packing list
integrated host x1, power cord x1, manual x1, certificate x1, warranty card x1
After-sales instructions
Warranty days: 365 days
