Defelsko PosiTector 6000 FTS3 Coating Thickness Gauge Advanced thick coating probe
SEAdvanced version imported from the United States, magnetic Induction thickness measurement, thickness measurement range 0~6000 μm, error +/- 3%, split probe, for thick coating measurement such as cement, rubber, Resin, fire-proof coatings, touch screen operation, with calibrated certificate.
$1571.00/set
PromotionLoading...
Coupon
Model：
PosiTector 6000 FTS3
Similar products
-
DONGRU DR6000 Anticorrosive layer Thickness Gauge 0~6000μm$ 312.00SE -
Defelsko PosiTector 6000 FTS1 Steel plate Coating Thickness Gauge Split probe type$ 1081.00SE -
Defelsko PosiTector 6000 FT1 Portable platings Thickness Gauge, integrated magnetic Thickness Gauge$ 966.00SE -
Defelsko PosiTector 6000 FT3 Coating Thickness Gauge$ 1456.00SE -
German EPK MiniTest 735 F5 iron-based Thickness Gauge, measuring thickness 0~5000μm$ 1787.00SE
Defelsko PosiTector 6000 FTS3 Coating Thickness GaugeSPEC
Defelsko PosiTector 6000 FTS3 Coating Thickness GaugeDetails
Defelsko PosiTector 6000 FTS3 Coating Thickness GaugePacking list
- SKU
- NB001199
- Measurement principle
- Magnetic Induction
- Measurement range
- 0~6000μm
- margin of error
- ±3%
- Resolution
- 0.1μm
- probe
- FTS3 probe (general thick coating)
- statistical function
- Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation
- icon function
- Yes.
- Power Supply
- 3 * AAA alkaline battery
- Standards
- ISO 2178/2360/2808、PrEN ISO 19840、ASTM B499/D1186/D1400/D7091/E376/G12、BS3900-C5、SSPC-PA2等
- Calibrated Certificate
- Yes.
- Language
- Chinese, English
- Display screen
- 2.8-Inch color touchscreen
- Interface
- USB、Bluetooth
- supporting software
- PosiSoft Software Suite
- Machine Weight
- 137G (without battery)
- Machine size
- 127*66*25.4mm
- Data storage
- 250000 Measured values, 1000 groups
- Test environment
- Ferrous metal substrate nonmagnetic coating environment
- Defelsko calibrated standard
- STDP1
- screen image saving
- One hundred.
- Protection level
- IP65
- Measurement speed
- More than 180 readings per minute
PosiTector 6000 FTS3
Coating Thickness Gauge
Advanced version imported from the United States, magnetic Induction thickness measurement, thickness measurement range 0~6000 μm, error +/- 3%, split probe, for thick coating measurement such as cement, rubber, Resin, fire-proof coatings, touch screen operation, with calibrated certificate.
Introduction
The Defelsko PosiTector 6000 FTS3 Coating Thickness Gauge is an external probe type that uses the principle of electromagnetic induction thickness measurement to measure the thickness of non-magnetic coatings on magnetic metal substrates, such as rubber, fire retardant coatings, etc., with a thickness range of 0~6mm.The PosiTector 6000 FTS3 Coating Thickness Gauge has a wide probe diameter designed to measure thicker coatings, has good abrasion resistance, and is made of stainless steel for the hand-kneading section.
Recommended reading
★《How do you choose the Defelsko PosiTector 6000 Coating Thickness Gauge?》
★Defelsko PosiTector 6000 Series Coating Thickness Gauge Details (Text Version)
FAQ
QWhat industrial scenarios is this thickness gauge suitable for?
A
It is suitable for industrial environments that require measurement of thick protective coatings, such as steel structure fire-proof coatings, pipeline rubber anti-corrosion coatings, tank protective coatings and other thick coatings measurement. Because Probe has good wear resistance, it can be used frequently in the field and meets multiple international standards such as ISO and ASTM.
QDo the Defelsko 6000 series thickness gauges come standard with software?
A
This does not have a physical software CD, but PosiSoft software can be downloaded for free on the manufacturer's official website for downloading and viewing data reports.
QCan this Defelsko 6000FTS3 thickness gauge be used to measure Printing ink on Glass?
A
Hello, no, this one measures the coating thickness on the metal substrate.
QWhy can't the Defelsko Coating thickness gauge be charged?
A
Hello, there are two solutions: 1. It is equipped with 3 ordinary AA batteries, please open it and replace it; 2. It can also be connected to a computer for direct use, but it cannot be charged (powered by a USB cable).
QAnti-corrosion coatings available?
A
OK
QAre all Coating thickness gauges available for testing in the ISO 2178 standard?
A
Not necessarily, but this PosiTector 6000 FTS3 Coating thickness gauge can be considered.
