Specifications
| Measurement range | 1.0~270mm |
| Probe Frequency | 5Hz |
| Probe diameter | Φ13.5mm |
| Probe contact temperature | -10~70℃ |
| Lower limit of pipe measurement | Should 20mm * 3.0mm (standard TC510 probe) |
| measurement error | +/- 0.05mm (< 20mm )； +/- 0.5% H + 0.01 (over 20mm) |
| Display resolution | 0.01/0.1mm |
| unit system | mm/inch |
| Calibration method | One point calibrated, two point calibrated |
| Repeatability | ±0.05mm |
| Storage Capacity | 400 files, 100,000 thickness values |
| statistical function | Thickness Value Mode, Min/MAX Maximum Capture Mode, Difference/Reduction Rate Mode |
| Speed of sound | 500~9999m/s |
| Display | 2.4QVGA (320 × 240) color OLED screen, contrast ratio 10000:1 |
| Operating language | Chinese, English, Japanese, German and French are available in five languages |
| Interface | USB 2.0 full speed interface |
| Application Software | DataView software |
| Environmental temperature | -10~50℃ |
| Power Supply | Two 1.5V AA batteries |
| Operating Time | 35h |
| Host size | 149*73*32mm |
| Weight | 280G (including battery) |
Packing list
Thickness gauge host × 1, standard probe × 1, instrument box × 1, 1.5AA alkaline battery × 2, coupling agent × 1, data communication cable × 1, software CD × 1
After-sales instructions
Warranty days: 365 days
