Specifications
| Measurement range | Automatic 0.25mm-27mm; Multiwave check method 0.25mm-9mm; echo-echo method 0.25mm-13.5mm; pulse-echo method 1.5mm-27mm |
| Probe Frequency | 4Hz, 8Hz, 16Hz per second optional |
| Display resolution | 0.001/0.01/0.1mm |
| unit system | mm/inch |
| Storage Capacity | 400 files, 100,000 thicknesses and 1000 waveforms |
| statistical function | Thickness value, minimum thickness value, and maximum thickness value |
| Speed of sound | 500~9999m/s |
| Display | 2.4QVGA (320 × 240) color OLED screen, contrast ratio 10000:1 |
| Operating language | Chinese, English, Japanese, German and French are available in five languages |
| Environmental temperature | -10~50℃ |
| Power Supply | Two 1.5V AA batteries |
| Operating Time | 35h |
| Host size | 153*76*37mm |
| Weight | 280G (including battery) |
Packing list
Thickness gauge host, standard probe, instrument box, two alkaline batteries, coupling agent, operation manual, certificate of conformity, packing list, 1 data communication cable, 1 software CD-ROM
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12029/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
