Specifications
| Power | 500W |
| Power Supply | 220V，50/60Hz |
| Processing Capacity | 200~10000ml |
| Max. Processing Viscosity | 1000CP |
| Speed range | 10000~28000rpm |
| Rotation speed display | Scale/Digital Display |
| Rotation speed control | stepless speed regulation |
| Contact material | SS316L、FKM |
| Bushing material | Copper alloy |
| Environmental temperature | 5~40℃ |
| Allowable Relative Humidity | ≤80% |
| Process type | online processing |
| Dimension | 210*290*675mm |
| Weight | ~13kg |
| Encasement | carton |
| Base material | SS304 |
| Import and export outer diameter | 14 (hose interface) |
| Flow rate range | 1-15L/min |
| Use the highest temperature | 120℃ |
| Standard working chamber | Stainless steel jackless working chamber |
| Work head specification | 20DG |
| Mechanical sealing material | SiC, FKM, ceramics |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12055/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
