Specifications
| Measurement principle | magnetic Induction |
| Measurement range | 0~13000μm |
| margin of error | ±1~3%/±50μm |
| resolution | 1μm|10μm |
| Minimum measurement surface | 14mm |
| Minimum radius of curvature | Convex 15mm; Concave 40mm |
| probe | Integrated probe |
| Calibrated Certificate | Yes. |
| Calibrated mode | Factory calibrated, two point calibrated, zero point calibrated, single point calibrated |
| Unit display | μm |
| statistical function | Number of readings, average value, standard deviation, minimum limit, maximum limit, coefficient of variation |
| Interface | USB |
| Data storage | Last 5 Measured values |
| Power Supply | 2 AA batteries, rechargeable batteries can also be used |
| Standards | AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B 499, ASTM D 7091, ASTM E 376, ASTM G 12,BS 5599,EN 13523-1, IMO MSC.215(82), IMO MSC.244 (83) |
| Display screen | 2.4 " (6 cm) QVGA color TFT display, 320x240 pixels |
| Operating temperature | 80℃ |
| Operating temperature | -10~50℃ |
| Battery life | With 1 reading per second, it can work continuously for up to 24h |
| Protection level | IP64 |
| supporting software | ElcoMaster ® Software |
| Weight | 161G (including battery) |
| Dimension | 141*73*37mm |
Packing list
ELCOMETER Elcometer456 host x1, calibrated diaphragm x1, wristband x1, protective cover x1, AA battery x2, operation manual x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12189/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
