Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~5000μm(F)/0~2500μm(N) |
| margin of error | ±0.75% |
| Minimum measurement surface | 10mm |
| probe | Line probe |
| Calibrated Certificate | Manufacturer Certificate |
| Calibrated mode | Factory calibrated, zero calibrated, 2 point calibrated, 3 point calibrated, rough Calibration method "rough" |
| Unit display | μm/mm/cm/mils/inch/thou |
| statistical function | Number of readings, MIN Minimum, MAX Maximum, mean, standard deviation, coefficient of variation, single-valued statistics, chunk statistics (conforming to specifications/free configuration) |
| Interface | USB、Bluetooth |
| Data storage | 100000 Measured values |
| Power Supply | 2 AA (AA) batteries; optional rechargeable nickel-metal hydride battery, AA/HR6 type. Battery or rechargeable battery settings are optional to match Rated Voltage. |
| Standards | DIN EN ISO 1461、DIN EN ISO 2064、DIN EN ISO 2178、DIN EN ISO 2360 |
| system language | 20 languages |
| Display screen | LCD screen |
| Operating temperature | -10~60℃ |
| supporting software | Yes. |
| Weight | 210g |
| Dimension | 157*75.5*49mm |
| Storage temperature | -20~70℃ |
| Calibrate to international standards and norms | ISO international standards organization, SSPC American protective coatings association, "Swedish" Sweden, "Australian" Australia |
| limit monitoring | Output visual and auditory signals |
| Measurement speed | 70 readings per minute in single-value mode; 20 readings per second in continuous mode |
| continuous mode | For quickly identifying thickness changes |
| Standards | DIN EN ISO 2808、DIN EN ISO 3882、ISO 19840、ASTM B 244、ASTM B 499、ASTM D 7091、ASTM E 376、AS 3894.3、SS 184160、SSPC-PA 2 |
Packing list
Host, calibrated foil and reference board, operating instructions CD, soft bag and shoulder strap, AA battery × 2, manufacturer's certificate, MSoft7 basic version data transfer software.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12427/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
