Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~1250μm |
| margin of error | ±3% |
| resolution | 1μm |
| Minimum measurement surface | Φ10mm |
| minimum radius of curvature | Convex 1.5mm; Concave 20mm |
| thinnest matrix | 0.5mm |
| probe | F1/N1 integrated probe |
| icon function | none |
| Power Supply | 4 * AAA 1.5V alkaline battery |
| Calibrated Certificate | none |
| system language | Chinese |
| Display screen | LCD screen |
| companion software | none |
| Weight | 120g |
| Dimension | 150*55.5*23mm |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
Packing list
Host x1, standard test piece x1, matrix x1, AAA alkaline battery x1, certificate x1, manual x1, Encasement box x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1251/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
