Specifications
| Measurement principle | Eddy Current |
| Measurement range | 0~1250μm |
| margin of error | ±2% |
| Resolution | 0.1μm |
| probe | Split N1 probe |
| Power Supply | 2 * AA 3V battery |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | 128 * 64 dot matrix liquid crystal LCD |
| Interface | USB |
| supporting software | Yes. |
| Machine Weight | 340g |
| Machine size | 125*67*31 mm |
| Data storage | 100 Measured values, 5 groups |
| Unit display | μm/mils |
| Battery life | More than 200h (when the backlight is not turned on) |
Packing list
Host x1, probe x1, calibration shim x5, battery x2, manual x1, warranty card x1, certificate x1, screw driver x1, data software x1, special instrument case x1
After-sales instructions
Warranty days: 730 days
1. After the instrument confirms the receipt, it will be replaced free of charge within 3 months if there is a quality problem under the normal operating conditions of the "Instruction Manual";
2、Warranty period2years (except consumables, probes, sensors, cables)；
3. After-sales service is provided by the original factory;
4. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1266/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
