Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 0~2500μm |
| margin of error | <50μm±1μm ≥50μm<1000μm±2% ≥1000μm±3% |
| Resolution | 0.1μm|1μm |
| probe | Line probe |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Power Supply | 1.5V |
| Display screen | Digital LCD display (backlight can be self-selected switch) |
| Interface | USB、RS-232C |
| Machine Weight | 0.34kg |
| Data storage | About 39,000 with a MIN Minimum of 0.1 μm |
| Interface | Computer (USB) output or printer (RS-232C) |
| Machine size | 75*145*31mm |
| Measurement area | Φ5㎜ |
| Operating temperature | 0~40℃ |
| Battery life | 100h |
| Power Consumption | 80mW (without backlight) |
| storage channel | 50 |
| probe | Touch (LEP-J) or (LHP-J) |
Packing list
Substrate x1, standard sheet x1, alkaline battery x4, probe x1, leather case x1
After-sales instructions
Warranty days: 365 days
During the warranty period of this product, the maintenance is free of charge, except for human factor damage and wearing parts, such as probes, liquid crystal displays, shells, standard films, and substrate plates. The cost of postage shall be paid by the sender.This product is not suitable for 7*15 no reason to return or exchange,After receiving the goods, if there is a quality problem, the user can apply for a replacement.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12671/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
