Specifications
| Probe frequency | 5MHz |
| Probe style | Split probe |
| Probe diameter | F4mm |
| Probe contact temperature | -10~60℃ |
| Lower limit of pipe measurement | F20 * 3mm |
| Measurement error | ±(1%H+0.04)mm |
| Display resolution | 0.1mm /0.01mm optional |
| unit system | mm/inch |
| Storage Capacity | 500 pieces |
| Sound speed range | 1000~9999m/s |
| Display | LED liquid crystal display |
| Operating language | Chinese |
| Application software | without |
| Power | AA type alkalinity battery 1.5V (2 *) |
| Operating Time | 250H (without backlight) |
| Host size | 150*74*32mm |
| Weight | 238g |
| Application | Film thickness measurement of plastics, Pottery and porcelain, Glass, Metals (such as Steel, Aluminum, Cast Iron, Copper, etc.), Glass Fibers and Miscellaneous Any good conductor of ultrasonic waves, and measurement of the speed of sound of the material |
| Optional probe | 2MHz (cast iron probe), 7MHz (micro-diameter probe) (Φ15 mm × 2.0 mm), 5MHz (high temperature probe) |
| Probe diameter | Φ6 mm (optional) Φ10 mm (optional) Φ12 mm (optional) |
| Calibrating block | 4.0 mm (steel) |
| Measurement speed | 4 times/sec for single point measurement, 20 times/sec for scanning mode |
| Film thickness capturing capability | Yes. |
Packing list
Host x1, probe x1, 4.0 mm steel calibrating block x1, coupler x1, battery x2
After-sales instructions
Warranty days: 730 days
1. After the instrument confirms the receipt, it will be replaced free of charge within 3 months if there is a quality problem under the normal operating conditions of the "Instruction Manual";
2、Warranty period2years (except consumables, probes, sensors, cables)；
3. After-sales service is provided by the original factory;
4. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
