Specifications
| Lighting method | DI/8 (Scattering Light source, 8 degree Viewing Angle) SCI (conforms to CIE No. 15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c) |
| Integrating sphere size | Φ40mm |
| Lighting source | CLED |
| Sensors | Array Sensors |
| Wavelength range | 400~700nm |
| Light spectrum Bandwidth | 10nm |
| Measurement time | 2s |
| Measurement caliber | Φ11mm |
| Repeatability of chromatic value | Standard deviation Delta E * ab 0.08 |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | A、C、D50、D65 |
| display mode | Sample chromatic value (L * a * b, L * C * h), color difference value, pass judgment, Color bias, average value, generate test report, Light spectrum diagram |
| Color difference formula | ΔE*ab,ΔE*CH |
| Color Space | CIE-L*a*b,L*C*h |
| Chroma indicator | Dip colour fastness, discoloration fastness |
| data storage | 20,000 pieces of test data |
| Light source lifetime | 5 years 1.50 million times |
| Display | Full color true color screen |
| Operating language | Chinese, English |
| Interface | USB2.0 |
| Operating environment | 5~ 45 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage environment | _ -25 ℃ to 55 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Power supply Voltage | Rechargeable lithium battery 8.4V/2000mAh, dedicated adapter DC12V |
| Dimensions | 77*86*210mm |
| Weight | Approx. 550g |
| Color scheme | Unmatched |
| UV Light source | No UV Light source |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12688/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
