Specifications
| Lighting method | DI/8 (Scattering Light source, 8 degree Viewing Angle), SCI (according to CIE No.15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c) |
| Integrating sphere size | Φ40mm |
| Lighting source | CLED |
| Sensors | Array Sensors |
| Wavelength range | 400~700nm |
| Light spectrum Bandwidth | 10nm |
| Measurement time | 2s |
| Measurement caliber | Φ11mm |
| Repeatability of chromatic value | Standard deviation Delta E * ab 0.08 |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF,U30,CWF,U35 |
| display mode | Sample chromatic value (L * a * b, L * C * h), color difference value, pass judgment, Color bias, average value, generate test report, Light spectrum map/data, display measurement area, Light spectrum map/data, manually enter standard sample |
| Color difference formula | ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00 |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance |
| Chroma indicator | Homochromatic index MI, colour fastness, discoloration fastness |
| data storage | 20,000 pieces of test data |
| Light source lifetime | 5 years 1.50 million times |
| Display | Full color true color screen |
| Operating language | Chinese, English |
| Interface | USB2.0, Bluetooth |
| Operating environment | 5~ 45 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage environment | -25 ℃ to 55 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Power supply Voltage | Rechargeable lithium battery 8.4V/2000mAh, dedicated adapter DC12V |
| Dimensions | 77*86*210mm |
| Weight | Approx. 550g |
| Color scheme | Unmatched |
| UV Light source | No UV Light source |
| Other functions | Camera viewfinder, Formula Guide, mobile app |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12692/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
