Specifications
| Light source | CIE-A、CIE-C、CIE-D65 |
| follow the standard | ASTM D1003/D1044 ISO13468/ISO14782 JIS K 7105,JIS K 7361,JIS K 7136 |
| Measurement parameters | Haze (HAZE), Transmittance (T) |
| Light spectrum Response | CIE Light spectrum function Y/V (λ) |
| Wavelength Range | 400-700nm |
| wavelength interval | 10nm |
| optical path structure | 0/d |
| Illumination and sample aperture size | 16.5mm/21mm |
| range | 0-100% |
| Haze resolution | 0.01 unit |
| Haze Repeatability | ≤ 0.1 unit |
| Sample size | Thickness ≤ 150mm |
| show | 5-Inch TFT LCD screen |
| store data | 20,000 values |
| interface | USB port |
| Power Supply | 220V (with its own power cord) |
| Operating temperature | 0~45 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Storage temperature | -25 ℃~ 55 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Volume | 598*247*366mm |
| Standard | PC management software (Color QC) |
| optional | Measurement fixture, haze standard sheet |
Packing list
Host X1, PC management software (Color QC) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 3 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12697/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
