Specifications
| Lighting method | Reflection: d/8 (diffuse illumination, 8 ° direction reception); Transmission: d/0 (diffuse illumination, vertical direction reception) |
| Sensors | Dual Path Array Sensors |
| Wavelength range | 400~700nm |
| Available Light Sources | CLEDs (Full Band Equalized Led Light sources) |
| Measurement time | About 2s |
| Measurement caliber | Large Aperture (LAV): 2.54mm; Medium Aperture (MAV): 1.5mm; Small Aperture (SAV): 0.75mmx 1.0mm; Ultra Small Aperture (VSAV): 0.3mmx 0.8mm |
| Spectroscopic reflectance Repeatability | Standard deviation within 0.08% |
| Interface | USB |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,DLF,NBF,TL83,TL84 |
| Color difference formula | delta E * ab, delta E * CH, delta E * uv, delta E * cmc (2:1), delta E * cmc (1:1), delta E * 94, delta E * 00, delta Eab (Hunter), 555 shade classification |
| Power supply Voltage | 117-230VAC/50-60Hz |
| display mode | Transmission map/data, sample chromatic value, color difference value, pass/fail result, Color bias, Historical data, Color simulation, Manual input standard sample, Generate test report |
| Operating environment | 15 ℃ - 32 ℃ (60 ° F - 90 ° F); Relative Humidity 80% or less (at 35 ℃), no condensation |
| Dimensions | 583*330*304mm |
| Measurement conditions | Reflection Compatible with SCI (including specular reflection)/SCE (excluding specular reflection) (ISO7724/1, DIN5033 Teil7, JIS Z8722 Condition C, CIE No. 15, ASTM E1164) |
| Integrating sphere size | Φ152mm |
| wavelength interval | 10nm |
| bandpass filter | 5nm |
| Measurement range | 0%-200% |
| Reflectance resolution | 0.01% |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance, Hunter-lab, Munsell MI, CMYK. RGB. HSB |
| Chroma indicator | WI, YI, TI, homochromatic index MI, colour fastness, discoloration fastness, ISO luminance, A density, T density, M density, E density, APHA, Hazen, Pt-Co (platinum cobalt index), Gardner (Gardner index), Saybolt (Seibert index), Astm color, haze |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Repeatability of chromatic value | Delta E * ab 0.015, MAX Maximum 0.03 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12719/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
