Specifications
| Lighting method | D/8 (Scattering Light source, 8 degree Viewing Angle), SCI (including specular reflection component)/SCE (excluding specular reflection component) synchronous measurement function. (Compliant with CIE No.15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c standards. |
| Sensors | Dual Path Array Sensors |
| Measurement range | 0~200% |
| Available Light Sources | CLEDs (Full Band Equalized Led Light sources) |
| Measurement time | 0.5s |
| Measurement caliber | Φ11mm |
| Spectroscopic reflectance Repeatability | Standard deviation within 0.08% |
| Interface | USB |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CMF,U30,DLF,NBF,TL83,TL84 |
| Color difference formula | delta E * ab, delta E * CH, delta E * uv, delta E * cmc (2:1), delta E * cmc (1:1), delta E * 94, delta E * 00, delta Eab (Hunter), 555 shade classification |
| data storage | 20,000 pieces of test data |
| Power supply Voltage | Battery |
| display mode | Light spectrum chart/data, sample chromatic value, color difference value, pass/fail result, Color bias, display measurement area, historical data color simulation, manual input standard sample, generate test report |
| Operating environment | 0~45 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage environment | -25~ 55 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Dimensions | 350*300*200mm |
| Weight | About 4.5kg |
| Integrating sphere size | Φ40mm |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 5nm |
| Reflectance resolution | 0.0001 |
| Measurement time | About 1s |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance, Hunterlab, Munsell MI, CMYK, RGB, HSB |
| Chroma indicator | WI, YI, TI, homochromatic index MI, colour fastness, discoloration fastness, ISO luminance, 8 Glossiness, A density, T density, E density, M density |
| Battery life | Charging repeability, continuous measurement 20000 times, 7.4V/6000mAh |
| Lighting source life | 10 years 3 million times |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Display | 5-Inch full-color true color screen |
| Color scheme | can be matched |
| UV Light source | No UV Light source |
| Repeatability of chromatic value | Delta E * ab 0.015, MAX Maximum 0.03 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12721/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
