Specifications
| Measurement angle | 60° |
| Measurement range | 0~600GU |
| Repeatability | 0-100GU:0.2GU；100-600GU:0.2%GU |
| Graduation | 0.1GU|1GU |
| Measuring Areas | 2*3mm |
| Measurement mode | Simple mode and statistical mode |
| Standards | JJG 696-2002 |
| Interface | USB, Bluetooth (optional) |
| Data storage | Can store 100 master standards, 10,000 samples |
| Operating language | Simplified Chinese, English |
| Dimensions | 165*51*77mm |
| Weight | Approx. 400g |
| Power Supply | 3000mAh lithium battery |
| software | PC data management software |
| Operating Time | 25000 continuous measurements |
| Operating temperature | 0~40℃ |
| Relative Humidity | < 85% RH, no condensation |
| Measurement time | 1s |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 3 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12726/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
