Specifications
| Measurement mode | Piezoelectric ceramics (shear type) |
| Acceleration Measurement Range | 0.1~199.9m/s² |
| Speed Measurement Range | 0.1~199.9mm/s |
| Displacement Measurement Range | 0.001~1.999mm |
| Acceleration frequency range | 10Hz~1KHz(LO)，1KHz~15KHz(HI) |
| Speed frequency range | 10Hz~1KHz (LO) |
| Displacement frequency range | 10Hz~1KHz (LO) |
| Measurement error | ±5%Hz±2digits |
| Data output | Peak AC signal output (full scale display) |
| monitor | 3.5 digits LCD display |
| Automatic range switching | Yes. |
| Backlight display function | Yes. |
| Automatic shutdown function | Yes. |
| Operating temperature | 0~40℃ |
| Power | 9V battery |
| Weight | 147g |
| Dimensions | 67*30*183mm |
| Encasement mode | Aluminum Encasement |
| Standard outer box Capacity | 12PCS |
| Standard outer box size | 52*43*32.5cm |
| Standard Gross Weight | 11.93KG |
Packing list
Vibration meter X1, original battery X1, factory certificate X1, warranty card X1, manual X1, portable toolbox x1, long probe x1, short probe x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/12769/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
