Specifications
| Processing Capacity | 40L |
| Input Power | 120W |
| Input Power | 100W |
| Rated Voltage | 100~240V |
| Rated Frequency | 50/60Hz |
| Power | 130W |
| Speed range | 50~2200rpm |
| Rotation speed control Accuracy | ±3rpm |
| Rotation speed display | LED |
| Rotation speed Display resolution | ±1rpm |
| Max Torque | 60N.cm |
| Torque display | - |
| Safety protection | Overload protection LED light is on |
| Safety protection | The LED is on. |
| maximum viscosity | 50000mPa·s |
| Rotary collet clamping range | Φ0.5~10mm |
| Dimensions | 220*83*186mm |
| Machine Weight | 2.8kg |
| Protection level | IP21 |
| Environmental temperature | 5~40℃ |
| Allowable Relative Humidity | ≤80% |
| Interface | without |
Packing list
Host X1, quality assurance card X1, certificate of conformity X1, manual X1,
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13083/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
