Specifications
| Geometry | 60° |
| Measurement range | 0~200GU |
| Repeatability | ±1GU |
| Reproducibility | 1GU |
| Measuring Areas | 9*15mm |
| Error of indication | ±1.5,±1.5% |
| Division Value | 1GU |
| Standards | ISO 2813、GB/T 9754、ASTM D 523、ASTM D 2457 |
| Data Interface | USB interface, RS-232 |
| Display | TFT true color 3.5inch display |
| Operating language | Simplified Chinese, English |
| Dimensions | 160*75*90mm |
| Weight | About 350g |
| Power | 3200mAh lithium battery, more than 10,000 times in 8 hours |
| Application | Basic measurement of glossiness in paint, Coating, Printing ink, Plastic Electronics, Furniture, Pottery and porcelain, Hardware, Marble and other industries. Cost-effective, large color display, can display 3 sets of test data at the same time. |
| Chromaticity Response | Under CIE C light source, CIE 1931 (2 °) luminosity corresponds |
| Measurement time | 0.5s |
| Operating Temperature | 0~40℃ |
| Storage temperature | -20~50℃ |
| Relative Humidity | < 85% RH, no condensation |
| Standard accessories | charger, USB data cable, manual, parameter adjustment software tool (download from 3nh official website), calibration standard board |
| Optional accessories | Micro printer |
Packing list
host x1, charger x1, USB data cable x1, dust-free cloth x1, manual x1, warranty card x1, calibration standard box x1.
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 1 year.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1321/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
