Specifications
| Geometry | 60° |
| Measurement range | 0~1000GU |
| Sexual repeability | 0~100GU: 0.2GU; 100~1000GU: 0.2% |
| Measuring Areas | 9*15mm |
| Error of indication | ±1.5,±1.5% |
| Division Value | 0.1GU |
| Standards | ISO 2813, ASTM D 523, GB/T 9754 |
| Data Interface | USB interface, RS-232 |
| data storage | Basic mode 1000, statistical mode 5000, continuous mode 5000 |
| Display | TFT true color 3.5inch display, capacitive touch screen |
| Operating language | Simplified Chinese, English |
| Dimensions | 160*75*90mm |
| Weight | About 350g |
| Power | 3200mAh lithium battery, more than 10,000 times in 8 hours |
| software | GQC6 quality management software, Quality control report printing, more function expansion |
| Application | Paint, Coating, Printing ink, Eletroplating, Plastic Electronics, Hardware and other industries |
| Accuracy | Meet the requirements of JJG 696 first-class working glossiness instrument |
| Chromaticity Response | Under CIE C light source, CIE 1931 (2 °) luminosity corresponds |
| Measurement time | 1.5s |
| Operating Temperature | 0~40℃ |
| Storage temperature | -20~50℃ |
| Relative Humidity | < 85% RH, no condensation |
| Standard accessories | Horizontal charger, USB data cable, manual, CD-ROM (including quality management software), calibration standard board |
| Optional accessories | Micro printer |
Packing list
host x1, charger x1, USB data cable x1, dust-free cloth x1, manual x1, warranty card x1, CD x1, correction standard box x1.
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 1 year.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1324/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
