Specifications
| Measurement principle | eddy Current |
| Measurement range | 0~1250μm |
| margin of error | ±3% |
| resolution | 0.1μm |
| Minimum measurement surface | Φ7mm |
| Minimum radius of curvature | Convex 1.5mm Concave 9mm |
| thinnest substrate | 0.5 |
| probe | N |
| statistical function | Single measurement, continuous measurement |
| Data storage | 15 Measured values |
| Power Supply | lithium battery |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Operating Mode | Direct mode (DIRECT) and group mode (Appl) |
| Weight | 150g |
| shutdown mode | automatic |
Packing list
host X1, a set of standard pieces X1, aluminum matrix X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1068 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13252/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
