Specifications
| Measurement range | 0.8~ 300mm (steel, determined by the probe) |
| Probe diameter | Ф10mm |
| Probe contact temperature | -10~300℃ |
| Lower limit of pipe measurement | Ф20*3mm、Ф15*2mm |
| measurement error | ±(1%H+0.1)mm |
| Display resolution | 0.01mm |
| Calibrating block | 4.0Mm (steel) |
| Storage Capacity | 10 Thickness values, 5 Speed of sound values |
| Speed of sound | 1000~9999m/s |
| Display | 4-Bit LCD |
| Power Supply | AA type alkaline 1.5V battery (2 pcs) |
| Operating Time | 250h |
| Weight | 230G (including battery) |
| Application | Petroleum, chemical industry, metallurgy, shipbuilding, aviation, aerospace, etc |
| shutdown mode | Automatic (after three minutes of no operation) |
| Speed of sound | 0~9999m/s |
Packing list
Host X1, suitcase X1, 5P < unk > 10 probe X1, ZW5P probe X1, AA type alkaline battery X2 (section), coupling agent X1, random file X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1068 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13256/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
