Specifications
| Measurement range | 0.8~ 300.0Mm (steel, determined by probe), 5.0-40 mm cast iron |
| Probe diameter | Ф10mm |
| Probe contact temperature | -10~+60℃ |
| Lower limit of pipe measurement | Ф20*3mm、Ф15*2mm |
| measurement error | ±(1%H+0.1)mm |
| Display resolution | 0.1mm |
| Calibrating block | 4.0Mm (steel) |
| Storage Capacity | 100 thickness values and 5 Speed of sound values |
| Speed of sound | 1000~9999m/s |
| Display | 4-Bit LCD |
| Power Supply | AA type alkaline 1.5V battery (2 pcs) |
| Operating Time | 250h |
| Host size | 149*72*32mm |
| Weight | 200G (including battery) |
| Application | Petroleum, chemical industry, metallurgy, shipbuilding, aviation, aerospace, etc |
Packing list
Host X1, password box X1, 5MHz probe X1, (2.5MHz or 7MHz) probe X1, 4.0mm steel calibrated block X1, AA type alkaline battery X2 (section), coupling agent X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1068 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13261/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
