Specifications
| Measurement range | 0.75 to 300mm (steel, determined by the probe), 4.0 to 80mm (high temperature) |
| Probe diameter | Ф10mm |
| Probe contact temperature | -10~300℃ |
| Lower limit of pipe measurement | < unk > 20mm3.0mm (5P < unk > 10 probe, steel) |
| measurement error | ±(1%H+0.1)mm |
| Display resolution | 0.1mm |
| Zero proofreading | automatic |
| Storage Capacity | 5 groups of 500 thickness values, 5 Speed of sound values |
| Speed of sound | 1000~9999m/s |
| Display | Four large screen backlit digital display, adjustable contrast ratio |
| Power Supply | AA type alkaline 1.5V battery (2 pcs) |
| Operating Time | 100h |
| Application | Petroleum, chemical industry, metallurgy, shipbuilding, aviation, aerospace, etc |
| shutdown mode | Manual shutdown or automatic shutdown (after three minutes of no operation) |
| Speed of sound adjustment | OK |
Packing list
Host X1, suitcase X1, 5P < unk > 10/90 probe X1, ZW5P high temperature probe X1, host protective cover X1, random file X1, AA type alkaline battery X2 (section), coupling agent X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1068 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13263/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
