Specifications
| Measurement principle | magnetic Induction |
| Measurement range | 0~400μm |
| margin of error | One point calibrated (μm ) ： +/- [ 3% H + 1], two point calibrated (μm )： +/- [( 1~ 3) % H + 0.7] |
| resolution | 0.1μm |
| Minimum measurement surface | Φ3mm |
| Minimum radius of curvature | Convex 1mm |
| thinnest substrate | 0.2mm |
| probe | F400 |
| statistical function | Single measurement, continuous measurement |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Data storage | 495 Measured values |
| Voltage | 3.0V |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Operating Mode | Direct mode (DIRECT) and group mode (Appl) |
| Weight | 530g |
| Dimension | 270*86*47mm |
| shutdown mode | Manual/Automatic |
Packing list
host X1, standard piece set X1, base X1, F400 probe X1, charger X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1068 days
