Specifications
| Coating speed | 0.1~500mm/s |
| Conductor speed Accuracy | ±1％ |
| Spreader trip | 50~415mm |
| Precision of stroke length | ±2mm |
| Maximum film area | 515*300mm |
| Maximum test cardboard thickness | 9mm |
| Maximum test substrate thickness | 35mm |
| Vacuum Area | DIN A3 / Scrub |
| Vacuum Area | DIN A5, DIN A4, DIN A3, Scrub |
| Application width | ≤325mm |
| Minimum length of coating rod | 345mm |
| Maximum diameter of coating rod | Φ10mm |
| Miscellaneous film applicator width | ≤300mm |
| Miscellaneous film applicator height | 10~80mm |
| Applicable standards | ASTM D823 |
| Dimensions | 490*640*290mm |
| Machine Weight | 33Kg |
| Host Power Supply | 100~240VAC/50~60Hz |
| energy consumption | ≤50W |
| Display | 480 * 272 pixel TFT display |
| language | English, Spanish, Chinese, Polish, German, French, Italian, Japanese, Russian, Turkish |
| Control mode | 5-Key navigation switch, mouse and keyboard optional |
| Standard | Glass bed |
| Coating method | Wire rod/drawdown blade |
Packing list
Film Applicator × 1, Product Manual × 1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13363/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
