Specifications
| Measuring range | T~E：0.65~400mm；E~E：3.0~25mm |
| Probe frequency | 5MHz |
| Probe style | Split probe (D5301), dual crystal |
| Probe contact temperature | <60℃ |
| Measurement error | ± 0.04mm (Film thickness value < 9.99mm) ± (0.1% Film thickness value < 0.04) mm Film thickness value = 10~99.9mm; ± 0.3% Film thickness value Film thickness value > 100mm |
| Display resolution | 0.01mm/0.001inch |
| Measurement mode | T-E, E-E two measurement modes |
| Sound speed range | 1000~9999m/s |
| Display | 320 * 240 color display |
| Operating language | Chinese |
| Application software | without |
| Operating Temperature | -20~50℃ |
| Storage temperature | -20~50℃ |
| Power | 2 * AA battery |
| Host size | 115*64*27mm |
| Weight | 220G (including battery) |
| Measurement speed | Ordinary measurement 2 times/second; high-speed measurement 10 times/second |
| Upper/Lower limits | √ |
| Storage Capacity | 5200 |
| Data output | Software Free |
Packing list
Host x1, probe (D5301) x1, coupling agent x1, AA battery x2, user manual x1, instrument case x1, USB data cable x1, data disc x1
After-sales instructions
Warranty days: 760 days
1. After-sales service is provided by the original factory;
2. The whole machine is guaranteed for two years, and wearing parts and consumables are not covered by the warranty (such as probes, LCD screens, casings, data cables, couplants, etc.);
3. The following two situations need to be repaired for a fee:
A. It is used under normal conditions, and there is a failure, but it has been exceededtwoannual warranty;
B. Use under abnormal circumstances, including man-made physical damage, failure to operate in accordance with the instructions and precautions.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1339/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
