Specifications
| Measuring range | T~E：1.4~200mm；E~E：3.0~25mm |
| Probe frequency | 5MHz |
| Probe style | Split probe (D5301 penetrating coating probe) |
| Probe contact temperature | <60℃ |
| Display resolution | ± 0.1mm (measurement greater than 100mm), ± 0.01mm (measurement less than 100mm) |
| unit system | mm/inch |
| Measurement mode | Standard, MIN Minimum, Difference Value, Average, Upper and Lower Limit Settings |
| Sound speed range | 1000~9999m/s |
| Display | 320X240 four-bit color TFT dot matrix liquid crystal display |
| Operating language | Chinese |
| Data Interface | USB |
| Application software | without |
| Operating Temperature | -20~50℃ |
| Storage temperature | -20~50℃ |
| Power | 2 * 7 AAA battery |
| Operating Time | 24h |
| Host size | 133*75*29mm |
| Weight | 260G (including battery) |
| Measurement speed | Ordinary measurement 2 times/second; high-speed measurement 10 times/second |
| Shutdown method | 1 minute, 3 minutes, 5 minutes automatic shutdown optional |
| Optional probe | D5008、D5113、D7006、D7004、D2012 |
Packing list
Host x1, probe (D5301) x1, coupling agent x1, AA battery x2, user manual x1, instrument case x1
After-sales instructions
Warranty days: 760 days
1. After-sales service is provided by the original factory;
2. The whole machine is guaranteed for two years, and wearing parts and consumables are not covered by the warranty (such as probes, LCD screens, casings, data cables, couplants, etc.);
3. The following two situations need to be repaired for a fee:
A. It is used under normal conditions, and there is a failure, but it has been exceededtwoannual warranty;
B. Use under abnormal circumstances, including man-made physical damage, failure to operate in accordance with the instructions and precautions.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1340/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
