Specifications
| Processing Capacity | 30L |
| Speed range | 20~1300rpm |
| Timer Range | 0~9999min |
| Stick size | Ф16×720mm |
| Dimension | 320*220*770mm |
| Machine Weight | 11kg |
| Power supply Voltage | Ac100V-230V |
| Max. Torque | 900mNm |
| Motor Power | 150W |
| Rotary collet clamping range | ≤Φ13mm |
| maximum viscosity | 30000mPa·s |
Packing list
Host X1, Stir head X1 (pcs), baseplate X1, cross right-angle chuck X1, main benchmark (Φ16X720mm) X1, warranty card X1, certificate X1, manual X1
After-sales instructions
Warranty days: 365 days
1 year original factory warranty (except consumables, electrodes, reagents, etc.) except for man-made damage, free warranty during the warranty period to replace accessories. Paid services are provided after the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13435/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
