Specifications
| Force range | 10 ~ 1000kPa |
| Indication resolution | 0.1kPa |
| Error of indication | ±1% |
| Indication of variability | ≤1% |
| Test disk surface horizontal longest direction parallel error | ≤ 0.0005mm/square millimeter |
| stretching speed | 1~220mm/min |
| Adhesive pressure setting range | (99~ 1999) N adjustable |
| Pressurization time setting range | (1~ 200) seconds adjustable |
| Power | AC220V ± 22V 50Hz 0.5A should be reliably grounded |
| Dimensions | 335*325*515mm |
| Net Weight | 33kg |
| Service life of Chinese measurement and control LCD | About 50,000 hours |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13519/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
