Specifications
| Measuring range | 20 ~ 6000kPa |
| resolution | 0.1kPa |
| Error of indication | ±1% |
| Indication of variability | ≤1% |
| Oil delivery speed | 170±15mL/min |
| Clamping Force | 0 ~ 1400Kpa |
| System tightness | 1Min pressure drop < 10% Pmax |
| Upper clamp ring aperture | F (31.5 ± 0.05) mm |
| Lower clamp ring aperture | F (31.5 ± 0.05) mm |
| Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
| Oil delivery speed | 10 times/65 seconds |
| Power | AC100-240V 50/60Hz 0.5A should be reliably grounded |
| Air source pressure | (0.6~ 0.8) MPa, gas source user-provided |
| gas consumption | 0.4m3/h |
| Dimensions | 380*240*530mm |
| Net Weight | 33kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13525/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
