Specifications
| Error of indication | ±1% |
| Indication variability | ≤1% |
| bending length | 50mm、25mm、10mm(±0.1mm) |
| Test speed | (200 +/- 20) °/min, in the case of bending 15 °, the bending time is not less than 3s and not more than 20s |
| bending length | 50mm |
| bending angle | Adjustable from 0 to 90 °, commonly used (15 +/- 0.3) °, (7.5 +/- 0.3) ° |
| Fixture width | 38±0.1mm |
| Measurement range | 50~5000mN |
| Resolution | 1mN |
| Applicable material | For paper, Cardboard and sheet materials, not for corrugated fibreboard |
| Chinese measurement and control LCD screen service life | About 50,000 hours |
| Power supply Voltage | AC220V +/- 22V 50Hz 0.5A should be reliably grounded |
| Dimensions | 330*340*290mm |
| Net Weight | 14Kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13528/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
