Specifications
| test range | 0 ~ 100kgf (0 ~ 200lbf, 0 ~ 1000N) |
| precision | ±0.5% |
| Parallelism between Upper/Lower pressure plates | ≤1:4000 |
| Measurement stroke | 76mm |
| Test speed | 1-50mm/min (0.04‒2.00 in/min) |
| return speed | 60mm/min(2.24in/min approx.) |
| Plate size | 125 × 125mm (upper pressure plate: 125 × 125mm, lower pressure plate: 170 × 125mm) |
| Power | 110-240V, 50/60 Hz |
| Dimensions | 380×240×530mm |
| Net Weight | 40kg |
| unit | N, lb,kgf |
| Measurement stroke | 76mm（3in） |
| data transmission | RS232, WIFI |
| Software optional | Experimental Data Management System |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13531/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
