Specifications
| Measuring range | 0~30N |
| resolution | 0.01N |
| Indication Accuracy | ±1% |
| Indication of variability | ≤1% |
| Spherical radius of two contact measurement heads | 5mm |
| Test speed | 50±2.5mm/min |
| Probe relative movement distance | 9.5±0.5mm |
| Probe pair neutral | ≤0.2mm |
| Two probe opening distance | 40~120mm |
| Measurement of Cup height | 10~180mm |
| Service life of Chinese measurement and control LCD | About 50,000 hours |
| Power | AC220V ± 22V 50Hz 0.5A should be reliably grounded |
| Dimensions | 500×270×330mm |
| Net Weight | 30kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13533/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
