Specifications
| Measurement angle | 20°/60°/85° |
| Measurement range | 0~99.9 100~2000(20°)；0~99.9 100~1000(60°)；0~99.9 100~160(85°) |
| Repeatability | 0.2% |
| Reproducibility | 0.5% |
| Measuring Areas | 10*10mm(20°)；10*20mm(60°)；8*30mm(85°) |
| Measurement port size | 11*38mm |
| Standards | GB9754、GB9966、GB/T13891、JJG696-2002、ISO2813、ASTMD523、DIN67530 |
| Interface | USB Interface, Bluetooth |
| Operating language | Chinese |
| Dimensions | 137*38*64mm |
| Weight | 380g |
| Power Supply | One AA battery or rechargeable battery |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13540/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
