Specifications
| Force resolution | 1N |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Zero Return Error | ±0.1%FS |
| deformation error | ±1mm |
| Stacking test Preset load Relative fluctuation | ±2% |
| Pressurization speed | 1~300mm/min |
| Pressurization speed relative error | +/- 2% (within 1~ 300mm) |
| return speed | 1~300mm/min |
| Pressurization speed | 10mm/min (adjustable) |
| Stacking test pressurization speed | 2mm/min (adjustable) |
| Smoothness of Upper/Lower platens | ±0.25mm |
| Plate parallelism | ≤1.5mm |
| Force range | 0.2~10KN(1000kg) |
| Plate size | 800*800mm |
| Dimensions | 1150*800*1400mm |
| Power supply Voltage | AC380V +/- 22V 50Hz 10A should be reliably grounded |
| Working Travel | 800mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/13553/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
